Angle capable, 30,000 pounds pull back, 12,000 pounds main hoist, 22 foot stroke with calibrated autohammer, pipe spinner, and 500 cfm/210 psi onboard compressor. Capacity: core N─3,500 ft, H─2,500 ft, P─1,500 ft. DOT SPT autohammer calibration sheet.
Rubber-tracked augering and coring rig with remote control, CME autohammer, angle-capable, Cummins turbocharged diesel, 28,275 pounds retraction force, 18,650 pounds pulldown force, 7,700 foot-pounds of torque, and rotation speeds to 800 rpm. Spec sheet.
Versatile, self-contained rubber-tracked augering and coring rig with calibrated autohammer, 8,200 pounds retraction force, 18,600 pounds pulldown force, 7,700 foot-pounds of torque, and rotation speeds to 800 rpm. Capacity: 8.25-inch auger─150 ft, core HQ─400 ft. DOT SPT autohammer calibration sheet.
50 HP JKS Boyles Super300U electro-hydraulic or diesel-hydraulic drill, can be set up on tracks or skids. Can be equipped with either surface or underground masts and winches. Capacity: AQ rods 1,600 ft, BQ 1,200 ft, NQ 800 ft.
75 HP permissible electro-hydraulic drill or diesel-hydraulic with a synchronized chuck-H head and load sensing hydraulic technology. Hole depth limits: core B─1,300 ft, N─1,000 ft, H─500 ft, 6-inch─300 ft.
Two permissible 75 HP electro-hydraulic or diesel-hydraulic drills with a synchronized chuck-N head and load sensing hydraulic technology. Hole depth limits: core B─3,000 ft, N─2,000 ft, H─1,500 ft. Hagby-Asahi AB is a Sandvik company.
Aluminum-framed, heli-portable, pneumatically- or electrically-powered drill, can be set up on tracks or skids.
Environmental sampling and monitoring of soil, soil gas, groundwater, and installation of small diameter prepacked screen monitoring wells with Geoprobe DT22 Soil Sampling System. Effective in sand, tight silt, swelling clay, and small gravels from the ground surface to depths of 100+ feet. Minimizes surface and subsurface disturbance by creating only small diameter bore holes.
Multiple pneumatically- or hydraulically-powered, permissible, post-mounted drills for use in tight-access locations and gassy mines. Man-portable and suited for confined-space drilling at any angle. Can be used in return airways.
Two self-contained, versatile W/Five drills on Morooka MST-800 rubber track carriers designed for low-impact footprints on soft terrain. Used for drilling on tundra, playas, and marshes, as well as regular terrain where tracked access is required. Used by agreement with Heli-Port Drilling, Inc. of Grand Junction.
International Eagle tandem axle truck with 8,000 lb crane and 2,000 gallon under bed water tank
GMC support truck, Caterpillar engine, 10-ton crane with hydraulic outriggers, PTO air compressor
GMC C4500 4WD flat bed truck
Dodge 4500 4WD utility bed service truck with auto crane
Dodge 3500 4WD utility bed service truck with fuel transfer tank
BigTex 25PH pintle ring, tandem axle trailer with equipment ramp
25,900 lb GVW
EPA Tier 4 Final certified Perkins engine
Model Expedition 2000
300 cfm/200 psi
Two-piece modular with pick points
Model CG-550/030/A - Pneumatic
45 gallon mixing tank
12 gallon hopper
16 GPM piston pump
Max output pressure 400 psi
Model CG-555GHES - Gasoline
45 gallon mixing tank with CG water meter
12 gallon hopper
10 GPM piston pump
Max output pressure 160 psi
Drilling water supply and effluent capture
200 to 500 gallon
Two 275-gallon caged IBC totes
Cross directional 4-way forklift channels
Weight 135 lbs (each empty)
Komatsu FG25T-14 forklift
Clarke 10,000-pound forklift
Multiple portable 20-foot and 40-foot Conex storage units
Truck transportable to job site
Mud tank sand separator on trailer
Bean 435 piston pump skid-mounted with 2-cyl Lister engine
10 hp 5kW generator
3-inch Honda centrifugal trash pump
2-inch Honda centrifugal trash pump
5.5 Briggs 2-inch high-pressure centrifugal freshwater pump
Lincoln Commander 300-amp portable welder with leads
Wireline packer equipment complete setup H, N
Grimmer Schmidt air compressor
Gardner Denver screw compressor
40 hp electric screw air compressor
Piaute PT610 tandem axle trailer
USBM BDGs and overcoring equipment
CSIRO HI Cell overcoring equipment
Hotsy portable power decontamination washer
Portable Miller welder
Miller MIG welder
Machine shop with overhead crane
Drill steel, bit, auger, casing inventory
